Sketching is connecting dots. Hands connect to the Brain. Ideas filter out from scribbling. Thank you pencil and paper.
The wall structure forms an interesting anti-seismic design:
- Loose secondary timber structure: Nuki (horizontal brace) spans across the primary columns and Mabashira (vertical stud) is lapped and nailed to the horizontal brace while the top and the bottom of the vertical stud remain unfixed to the wall/cill plate to allow for movement.
- Bamboo laths: the horizontal bamboo lath is used in round, gently rests and tied with hemp rope to a bamboo pin, which is pinned through to the primary column. The loose connection allows for movement.
- Hemp rope reinforcemnt: a seies of hemp rope is tied to the horizontal bamboo lath and a ribbon of hemp rope is embedded onto each layer of earth plaster coat to give tensile reinforcement to withstand seismic movements.
Often times, buildings reveal their most attractive state under-construction. Temporary floor joists extend beyond the footprint to create scaffold and working surfaces to aid its own construction. Self-sufficient nature of building under-construction
Square Plan continues to facinate me. The infinite possibility/combination of living space within a square…
A visitor? yes we have a hammock. When you wake up, let’s good morning eachother from above and below.
Tuning by ear to the 4th distance? The geometric ratio of the oud follows the harmonic ratios. Neck is 1/3 the string length and the rosette hole on the soundboard located at 1/3 string length as well.
Sometimes an idea comes from a desire to be high off the ground and float.
A sketch of a stone hut found in Mt. Hermel.
Ingenious use of local materials: stone, tree branches and a piled up prickley bush and tree bark forming the roof waterproofing
Timber lintel was the only element which has aged since the beginning of the stone wall.
The irregularlity propped up by little timber noggings…
When a space is small, each side starts to develop its own character: one side may tilt to ask you to recline, another side may bulge out to house a stove and then the eaves extend to allow for an interal soffit and a small writing table…
Salad combination.
Orange, Radish, Dill, Spring onion, Hazelnuts, Lemon Turmeric dressing… Crunchy and watery and herby.
Hut on Stilts started out from a roof frame. A decision to prefabricate frees one from building from ground up, but rather to build from top down. But always, one must check if your prefabricated pieces fit the narrow lane to the site.
A wish to sit in a small space with a breeze coming through
At some point, we thought about fixing off three oak trees.
